Innovative Tyres & Tubes Ltd

ITL 444

Tyre Size	Ply Rating	Application	Pattern	Section Width mm	Overall Dia. mm	Non Skid Depth mm	Maximum Load		Cold Inflation Pressure
							Single	Dual	Single		Dual
							7.00-15	12	Light Truck	ITL-444 (LUG)	205	770	17.0	1175	1030	90	620	90	620
7.50-15	14	Light Truck	ITL-444 (LUG)	220	800	15.0	1450	1375	94	650	94	650
7.00-16	12	Light Truck	ITL-444 (LUG)	200	796	18.0	1215	1065	90	620	90	620
7.00-16	14	Light Truck	ITL-444 (LUG)	205	807	18.0	1315	1160	100	690	100	690
7.50-16	16	Light Truck	ITL-444 (LUG)	220	835	17.4	1580	1390	110	760	110	760
7.50-16 (DB)	16	Light Truck	ITL-444 (LUG)	220	835	17.4	1580	1390	110	760	110	760
7.50-16 (DB)	18	Light Truck	ITL-444 (LUG)	220	835	17.4	1650	1450	115	795	115	795
8.25-16	16	Light Truck	ITL-444 (LUG)	230	835	17.6	1850	1750	110	760	110	760
8.25-16	18	Light Truck	ITL-444 (LUG)	230	855	17.6	1900	1800	115	795	115	795
8.25-16 (DB)	18	Light Truck	ITL-444 (LUG)	230	855	17.6	1900	1800	115	795	115	795
10.00-20	16	Truck and Bus	ITL-444 (LUG)	280	1065	21.5	3000	2630	115	795	105	725
10.00-20 (TB)	16	Truck and Bus	ITL-444 (LUG)	280	1065	21.5	3000	2630	115	795	105	725
10.00-20	18	Truck and Bus	ITL-444 (LUG)	280	1065	21.5	3080	2700	120	825	110	760
10.00-20 (TB)	18	Truck and Bus	ITL-444 (LUG)	280	1065	21.5	3080	2700	120	825	110	760
11.00-20	16	Truck and Bus	ITL-444 (LUG)	292	1110	21.5	3265	2865	115	795	105	725
11.00-20	18	Truck and Bus	ITL-444 (LUG)	292	1110	21.5	3355	2945	120	825	110	760
12.00-20	18	Truck and Bus	ITL-444 (LUG)	314	1140	21.5	3725	3265	115	795	105	725
10.00-20	16	Truck and Bus	ITL-444 E (LUG)	280	1065	21.5	3000	2630	115	795	105	725
